Specifications
| Basic parameters | |
|---|---|
| Dimension | 264.5 x 184.1 x 23.0mm |
| Weight | TBD |
| Device Color | black |
| LCD | 10.1 inch, 800x1280, 700nits |
| Touch Panel | 5-point tempered capacitive screen G+G |
| I/O | MICRO-SIM *1 (Optional) USB 2.0 Type-A *1 RS232 + RS232/RS485 Ethernet interface (100/100M) (Optional) USB 2.0 *1+USB 2.0 (default) / CAN *1+USB 2.0 (default)/CVBS *1 (Optional) Power DC Jack |
| NFC | Optional, 13.56MHz, Card reading distance: 4cm |
| Performance parameter | |
|---|---|
| CPU | ARM OCTA Core |
| OS | Android 12（GMS) |
| RAM | 4GB, Optional 2GB, Up to 8GB |
| Storage | 64GB, Optional 32GB, Up to 128GB |
| Standard Accessories | |
|---|---|
| WIFI Antenna | Standard, 2.4~2.5GHz/5.15~5.85GHz, 2±0.5dBi |
| GPS antenna( mushroom shape) | Standard |
| Adapter Cable | Standard, 8 PIN aviation plug to φ5.5 power port |
| 4G Antenna | Standard |
| Optional Accessories | |
|---|---|
| Bracket | Optional |
| Function Adapter | Optional, 12PIN to USB 2.0 *1+CAN*1+USB 2.0 (default)/CVBS*1 12PIN to full function RS232 + RS485/R232 12PIN to 100M RJ45 (with LED) 12PIN to 12 loose wires 1.2m |
| GPS Antenna | Optional |
| Power (One out of three) | Power adapter, 12V4A DC φ4.0 Adapter Adapter Cable, 8pin power cord to 4 loose wires (1.2M) Wide Voltage, 9~36V wide voltage input 12V±0.5V constant voltage output |
| Reliability | |
|---|---|
| Operate Temperature | -20 °C ~ 60 °C |
| Store Temperature | -30 °C ~ 70 °C |
| Humidity | 95% Non-Condensing |
| Rugged Feature | IP65 certified |
| Electrostatic Discharge | ±8kV contact discharge, ±15kV air discharge |
| Battery | |
|---|---|
| Battery | Optional |
| Capacity | 2000mAh/3.7V |
| Type | Built-in Li-polymer battery |
| Endurance | 30mins ( 50% volume sounds, 200 lumens brightness, 1080P HD video display by default ) |
 |
